TE DEUTSCH 0462-203-12141 Size 12 Nickel-Plated Socket Terminal
Manufacturer:DEUTSCH
Socket Terminal, 12 – 14 AWG, 3 – 2 mm² Wire, Nickel (Ni), 2.4 mm [.094 in] Pin Diameter, Terminates To Wire, DEUTSCH Common Contact
Contact Fabrication :Solid
Contact Size :Size 12
Crimp Type :Indent Crimp
Typical Current Rating (A):25
Terminal Type : Socket
Wire Size (AWG): 12 – 14
Wire Size (mm²): 3 – 2
Interface Plating : Nickel (Ni)
Primary Locking Feature : Integrated in Housing
Packaging Quantity :1250
Packaging Method :Crate
The TE Connectivity DEUTSCH 0462-203-12141 is a Size 12 solid socket terminal designed for reliable electrical connections in demanding automotive and industrial applications. It accommodates 12–14 AWG copper wire and uses crimp termination for secure wire-to-contact assembly.
Featuring nickel-plated contact surfaces and a 2.4 mm mating pin diameter, this terminal is suitable for compatible DEUTSCH connector systems that require Size 12 socket contacts. Its integrated-housing locking design helps retain the terminal in the appropriate connector housing.
