Molex 2145252021 Micro-Lock Plus 2-Pin Plug Crimp Housing, 1.25mm Pitch, Black

The Molex 2145252021, also identified as 214525-2021, is a 2-position plug crimp housing from the Molex Micro-Lock Plus connector family.

Designed for compact wire-to-wire electrical connections, this connector features a 1.25mm mating pitch and a single-row configuration. Its polarized housing and positive locking mechanism help ensure secure mating and prevent incorrect insertion.

The housing is manufactured from black polyamide (PA) with a UL94V-0 flammability rating. It is designed to operate over a temperature range of -40°C to +105°C and features a low-halogen material composition.

The 2145252021 uses compatible crimp terminals, which must be selected separately according to the wire size and connector specifications. The housing is intended for free-hanging, in-line cable assemblies rather than direct PCB mounting.

As part of the Micro-Lock Plus system, this compact 2-circuit housing offers a reliable connection solution for space-constrained electrical and electronic assemblies.
