TE 2310541-2 HVA 280 2-Position Split Header
Manufacturer:TE
Brand：TE Connectivity / AMP+
Part Number：2310541-2
Series：HVA 280
Product Type：High Voltage Automotive Connector
Connector Type：Split Header Assembly
Connector & Housing Type：Housing for Male Terminals
Number of Positions：2
Connector System：Wire-to-Panel
Contact Type：Tab
Contact Size：2.8 mm
Mating Tab Width：2.8 mm [.110 in]
Housing Color：Orange
Connector & Keying Code：B
Sealable：Yes
Operating Temperature：-40°C to +125°C
TE Connectivity 2310541-2 HVA 280 Split Header
The TE Connectivity 2310541-2 is a 2-position split header assembly from the HVA 280 connector system, designed for high-voltage automotive power applications.
TE identifies the product as “SPLIT HEADER ASSY, KEY B, HVA280, V0”. It is designed as a housing for male terminals and provides a wire-to-panel connection. The connector is sealable, uses an integrated primary locking feature and is designed for panel mounting.
